IPPC 1560TP2E Series |
| |
- 4:3 15" XGA Fanless Panel Computer
- Powerful 2nd/3rd generation Intel® Core™ processor
- Two expansion slots for add-on PCI or/and PCIe cards
- Optional 3.5G/Wi-Fi module/2.5" HDD/3 x COM/GPIO/DIO/Dimming Control Button
- Front accessible USB2.0 for easy of field maintenance
- Metal housing with robust aluminum front bezel for harsh environment
- IP65 compliant front panel
- Support fieldbus module, JMobile HMI and CODESYS SoftLogic(optional)
- Optional: wide range DC power input model/isolation protection DC power input model
|
|
|
|
|
|
|
 |
|
| |
IPPC 1632P |
| |
- Intel® Atom™ D2550,双核,低功耗 CPU
- 强固金属铝制，无前挡板，适用于严苛环境
- 10 点 P-Cap 点触摸，无挡板冲洗的前端设计
- 双 GbE/2nd 显示-VGA/Line-out
- USB x 4/2 x Mini-PCIe 插槽/1 x CFast/2 x RS232/422/485
- DDR3 4GB/2.5" HDD 支架
- IP66 兼容前面板
- 支持现场总线模块, JMobile HMI, Citect SCADA和CODESYS SoftLogic (可选)
- 安装支持: panel/wall/stand/VESA 100mm x 100mm
- 宽范围电源输入 12V~ 30V DC
|
|
|
|
|
|
|
 |
|
| |
IPPC 1640P |
| |
- Intel® Celeron® quad core processor J1900, up to 2.42GHz, 2M L2 Cache
- Metal housing with robust aluminum front zero bezel for harsh environment
- 10 points P-Cap multi-touch with zero bezel flush front design
- Dual GbE/2nd display-VGA/ Line-out/PS2 KB/MS
- USB x 3/2 x mini-PCIe sockets/1 x CFast/2 x RS232/422/485
- DDR3L 4GB/2.5” HDD bracket
- IP66 compliant front panel
- Support fieldbus module, JMobile HMI and CODESYS SoftLogic(optional)
- Mounting support: panel/wall/stand/VESA 100mm x 100mm
- Wide range power input 12~30VDC
|
|
|
|
|
|
|
 |
|
| |
IPPC 1840P |
| |
- Intel® Celeron® quad core processor J1900, up to 2.42GHz, 2M L2 Cache
- Metal housing with robust aluminum front zero bezel for harsh environment
- 10 points P-Cap multi-touch with zero bezel flush front design
- Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS
- USB x 3/2 x mini-PCIe sockets/1 x CFast/2 x RS232/422/485
- DDR3L 4GB/2.5” HDD bracket
- IP66 compliant front panel
- Support fieldbus module, JMobile HMI and CODESYS SoftLogic(optional)
- Mounting support: panel/wall/stand/VESA 100mm x 100mm
- Wide range power input 12~30VDC
|
|
|
|
|
|
|
 |
|
| |
IPPC 1960T |
| |
- 4:3 19" SXGA Fanless Panel Computer
- Powerful 2nd/3rd generation Intel® Core™ processor
- Two expansion slots for add-on PCI or/and PCIe cards
- Optional 3.5G/Wi-Fi module/2.5" HDD/3 x COM/GPIO/DIO/Dimming Control Button
- Front accessible USB2.0 for easy of field maintenance
- Metal housing with robust aluminum front bezel for harsh environment
- IP66 compliant front panel
- Support fieldbus module, JMobile HMI and CODESYS SoftLogic (optional)
- Wide range DC power input model
|
|
|
|
|
|
|
 |
|
| |
IPPC 2132P |
| |
- Intel® Atom™ D2550, 双核, 低功耗CPU
- 强固金属铝制，无前挡板，适用于严苛环境
- 10 点 P-Cap 点触摸，无挡板冲洗的前端设计
- 双 GbE/2nd display-VGA/Line-out
- USB x4/2 x Mini-PCIe插槽1 x CFast/2 x RS232/422/485
- DDR3 4GB/2.5" HDD支架
- IP66兼容前面板
- 直冲现场总线模块, JMobile HMI, Citect SCADA 和CODESYS SoftLogic (可选)
- 安装支持: panel/wall/stand/VESA 100mm x 100mm
- 宽范围电源输入12V~ 30V DC
|
|
|
|
|
|
|
|
|
|
 |
|
